Max Power CT HYD 550 Hydraulic Tunnel Thruster

Description

Tunnel Bow/ Stern Thruster – Hydraulic Tunnel Thruster

The HYD 550 is designed for motor boats and deep footed sailing yachts ranging from 65’-140’.

  CT550 is ready to enlarge the range of MAX POWER Tunnel Thrusters for boats up to 45m. All parts that are in the water are designed with best hydrodynamic profile to avoid turbulence. It is the most powerful tunnel thruster in D400 tunnel size with 4 blade propellers in metallic material to guarantee maximum thrust performance. Counter rotating system offers higher efficiency on thrusting with left side and right side pitch props in order to have same results in both directions.

CT 550  Specifications

• Typical Boat Size – 65 to 140 foot

• Propellers – 2 x 4 blade counter rotating

• Maximium Thrust – 560 to 630 kgf

• Hydaulic power – 42 – 50kW

• Tunnel Diameter (Inside) – 400mm

• Tunnel Thickness – 9 to 10mm

• Weight – 65 kg
