Description
Windlass – X3 with Capstan
Chromed Bronze – Best suited for boats/ yachts from 40 to 65 foot
- Watertight stainless steel ball bearings in the base
- Independent gipsy and drum operation
- Rope and chain combination gypsy
- Manual chain release
- Manual override
- Chain counter pre-setting as standard
- Motor IP-rating 66 (12/24V)
- Anodised marine aluminium gearbox
- 3 years of warranty
- If you require or have different sized chain, please contact us with the chain size and Pitch measurement.
| Construction | Chromed Bronze | ||
|---|---|---|---|
| Power | 12 volts | 12 volts | 24 volts |
| Motor Size | 1500 watts | 1700 watts | 1700 watts |
| Consumption | 150 Amps | 180 Amps | 90 Amps |
| Max. Pull | 1200kg | 1600kg | 1695kg |
| Lift Working Load | 165kg | 200kg | 215kg |
| Max. Lift Load | 600kg | 800kg | 850kg |
| Hauling speed | 17 to 40m per min | 14 to 32m per min | 15 to 32m per min |
| Weight | 35kg | 38kg | 38kg |
Standard Equipment – What comes in the box?
- Complete Windlass with choice of chain gypsy and motor size
- Dual direction Solenoid pack
- Handle
- CD/ Instruction manual
| SX3 | GYPSY TYPE | ROPE TYPE | LOFRANS PART NUMBER | ||
| 1500 Watt – 12 Volt | 1700 Watt – 12 Volt | 1700 Watt – 24 volt | |||
| With Drum | 8mm, ISO 4565 / DIN 766 | 14mm, 3-strand | 601079 | 600064 | 600068 |
| 10mm, DIN 766 | 16mm, 3-strand | * | 602101 | 602103 | |
| 10mm, ISO 4565 | 16mm, 3-strand | 472865 | 473208 | 473252 | |
| 12mm, ISO 4565 / 13mm, DIN 766 | 18mm, 3-strand | 601084 | 473004 | 473005 | |
