Lofrans SX3 Vertical Windlass with Capstan

Description

Windlass – SX3 with Capstan

Stainless Steel – Best Suited for boats/ yachts from 40 foot to 65 foot

The standard features that you can find in every SX series windlass are :

• Compact round base design
• Marine AISI 316L Stainless Steel construction
• IP67 rated heavy duty electric motor
• Anodised marine aluminium gearbox
• Watertight stainless steel ball bearing in the base (for better functionality and zero maintenance) which is a unique features in the windlass market.
• The clutch is made by two conical discs connected to the main shaft by two parallel planes on the shaft, in order to avoid using keys and allocate the weight load properly
• There is a sensor in the base so they can be connected to a chain counter
• Manual override so that the chain or rope can be recovered manually in case of electric function failure
• 3 years limited warranty
• If you require or have different sized chain, please contact us with the chain size and Pitch measurement.
• NOTE – a chain pipe will be needed for this windlass.

Standard Equipment – What comes in the box?

• Complete Windlass with selected choice of chain gypsy and motor size
• Dual direction Solenoid pack
• Handle
• CD/ Instruction manual
•
