Description
Windlass – Royal
- Marine anodised aluminium body
- Independent Gypsy and drum operation
- Manual chain release
- Manual override
Standard Equipment – What comes in the box?
- Complete Windlass with selected choice of chain gypsy
- Dual direction Solenoid pack
- Handle
- CD/ Instruction manual
If you require or have different sized chain, please contact us with the chain size and pitch measurement.
|
Motor Size |
Manual |
|
Maximum load (kg) |
400 |
|
Maximum load lift (kg) |
200 |
|
Lift working load (kg) |
50 |
|
Net weight with drum (kg) |
10 |
| ROYAL | GYPSY TYPE | LOFRANS PART NUMBER |
| With Drum | 6mm, ISO 4565 / DIN 766 | 187323 |
| 8mm, ISO 4565 / DIN 766 | 404725 | |
| 10mm, DIN 766 | 600079 | |
| 10mm, ISO4565 | 220002 |
