Description
Windlass – RAZZA anchor winch
Main Features:
- Marine AISI 316L Stainless Steel construction
- Manual chain release
- Chain & rope management by the spring loaded arm
- IP67 motor cover
- Automatic free fall available as an option
Standard Equipment:
- Dual direction solenoid pack
- Handle
- Gypsy for chain & rope
- QR code for Instruction manual
If you require or have different sized chain, please contact us with the chain size and pitch measurement.
|
Power |
500 Watts |
800 Watts |
|---|---|---|
|
Voltage |
12 Volts |
12 Volts |
|
Consumption |
65 Amps |
80 Amps |
|
Max. Pull |
630kg |
900kg |
|
Lift Working Load |
95kg |
125kg |
|
Max. Lift Load |
630kg |
900kg |
|
Hauling speed |
18m per min |
20m per min |
|
Suitable for boat size |
25 to 35 foot |
25 to 35 foot |
| GYPSY TYPE | LOFRANS PART NUMBER | |
| 500 Watt | 800 Watt | |
| 8mm, ISO 4565/DIN 766 | L636739 | L636699 |
| 6mm, ISO 4565 | L636738 | L636740 |
