Description
Windlass – Lion 1000 anchor winch
Painted white Aluminium Contruction
Main Features
- Low Profile
- Weight: 11 kg
- Rope and chain combination gipsy
- Manual chain release
- Heavy duty motor IP-rating 66 (12V)
- Chain counter magnet pre-set as standard
- Free Fall Option available
Standard Equipment – What comes in the box?
- Complete Windlass with selected choice of chain gypsy and motor size
- Dual direction Solenoid pack
- Handle
- CD/ Instruction manual
If you require or have different sized chain, please contact us with the chain size and pitch measurement.
|
Power |
12 volts |
|
Motor Size |
700 watts |
|
Consumption |
60 Amps |
|
Max. Pull |
575kg |
|
Lift Working Load |
105kg |
|
Max. Lift Load |
575kg |
|
Hauling speed |
23 to 26m per min |
|
Suitable for boat size |
20 to 35 foot |
| LION 1000 | CHAIN TYPE | ROPE TYPE | FREE FALL OPTION | LOFRANS PART NUMBER |
| Low Profile | 6mm, ISO 4565 / DIN 766 | 10-12mm, 3 strand | N/A | 636214 |
| 8mm, ISO 4565 / DIN 766 | 12mm, 3 strand | N/A | 636215 | |
| 6mm, ISO 4565 / DIN 766 | 10-12mm, 3 strand | YES | 636216 | |
| 8mm, ISO 4565 / DIN 766 | 12mm, 3 strand | YES | 636217 |
