Description
Windlass – Kobra anchor winch
Anodised Aluminium
- Independent gypsy and drum/ winch/ capstan operation
- Manual Chain/ Anchor release
- Manual override
- Heavy Duty IP-66 rating for the electric motor
- Comes with handle and control box
- 3 year limited warranty
Standard Equipment – What comes in the box?
- Complete Windlass with selected choice of chain gypsy and motor size
- Dual direction Solenoid pack
- Handle
- CD/ Instruction manual
If you require or have different sized chain, please contact us with the chain size and Pitch measurement.
|
Power |
12 volts |
24 volts |
|---|---|---|
|
Motor Size |
1000 watts |
1000 watts |
|
Consumption |
117 Amps |
59 Amps |
|
Max. Pull |
1250kg |
1325kg |
|
Lift Working Load |
160kg |
170kg |
|
Max. Lift Load |
625kg |
665kg |
|
Hauling speed |
25 to 35m per min |
25 to 35m per min |
|
Suitable for boat size |
25 to 35 foot |
35 to 45 foot |
| KOBRA | GYPSY TYPE | LOFRANS PART NUMBER | |
| 12 volt | 24 volt | ||
| With Drum | 6mm, ISO 4565 / DIN 766 | 600051 | 600513 |
| 8mm, ISO 4565 / DIN 766 | 220260 | 600514 | |
| 10mm, DIN 766 | 600052 | 471734 | |
| 10mm, ISO 4565 | 428747 | 220420 | |
