Description
Windlass – Falkon anchor winch
Anodised Aluminium
- Independent gypsy and drum/ winch/ capstan operation
- Manual Chain/ Anchor release
- Manual override
- Heavy Duty IP-66 rating for the electric motor
- 3 year limited warranty
- Lofrans advise the Falkon windlass is for yachts 45-55 feet in length overall
Standard Equipment – What comes in the box?
- Complete Windlass with selected choice of chain gypsy and motor size
- Dual direction Solenoid pack
- Handle
- CD/ Instruction manual
If you require or have different sized chain, please contact us with the chain size and pitch measurement.
| Power | 12 volts | 24 volts |
|---|---|---|
| Motor Size | 1700 watts | 1700 watts |
| Consumption | 135 Amps | 68 Amps |
| Max. Pull | 1700kg | 1800kg |
| Lift Working Load | 215kg | 225kg |
| Max. Lift Load | 850kg | 900kg |
| Hauling speed | 14 to 33m per min | 15 to 33m per min |
| Suitable for boat size | 45 to 60 foot | 45 to 60 foot |
| FALKON | GYPSY TYPE | LOFRANS PART NUMBER | |
| 12 volt | 24 volt | ||
| With Drum | 10mm, DIN 766 | 600063 | 600067 |
| 10mm, ISO 4565 | 220293 | 418511 | |
| 12mm ISO 4565 / 13mm DIN 766 | 404732 | 404733 | |
