Description
Windlass – Dorado anchor winch
Anodised Aluminium
- Rope and chain combination gypsy
- Rope chain management by the spring loaded arm
- Manual Chain/ Anchor release
- Manual override
- Heavy Duty IP-66 rating for the electric motor
- 3 year limited warranty
Standard Equipment – What comes in the box?
- Complete Windlass with selected choice of chain gypsy and motor size
- Dual direction Solenoid pack
- Handle
- CD/ Instruction manual
If you require or have different sized chain, please contact us with the chain size and pitch measurement.
|
Power |
12 volts |
12 volts |
|---|---|---|
|
Motor Size |
500 watts |
800 watts |
|
Consumption |
65 Amps |
80 Amps |
|
Max. Pull |
630kg |
900kg |
|
Lift Working Load |
95kg |
125kg |
|
Max. Lift Load |
345kg |
490kg |
|
Hauling speed |
18 to 24m per min |
20 to 25m per min |
|
Suitable for boat size |
15 to 25 foot |
20 to 35 foot |
| DORADO | GYPSY TYPE | ROPE TYPE | TYPE | LOFRANS PART NUMBER | |
| 500 wattage | 800 wattage | ||||
| Low Profile | 6mm, ISO 4565 / DIN 766 | 10-12mm, 3 strand | PORT | 409568 | 600048 |
| 8mm, ISO 4565 / DIN 766 | 12mm, 3 strand | PORT | 409569 | ||
