Description
Windlass – Cayman
- Marine aluminium anodised body
- Independent gypsy and drum operation
- Manual Chain release
- Manual Override
- Heavy Duty IP-66 rating for the electric motor
- 3 year limited warranty
Standard Equipment – What comes in the box?
- Complete Windlass with selected choice of chain gypsy and motor size
- Dual direction Solenoid pack
- Handle
- CD/ Instruction manual
If you require or have different sized chain, please contact us with the chain size and pitch measurement.
|
Power |
12 volts |
12 volts |
24 volts |
|---|---|---|---|
|
Motor Size |
700 watts |
1000 watts |
1000 watts |
|
Consumption |
110 amps |
150 amps |
80 amps |
|
Max. Pull |
1000kg |
1250kg |
1325kg |
|
Lift working load |
100kg |
170kg |
170kg |
|
Max. lift load |
525kg |
650kg |
650kg |
|
Hauling speed |
21 to 32m per min |
16 to 32m per min |
17 to 333m per min |
|
Weight |
24kg |
25kg |
25kg |
|
Suitable for boat size |
25 to 35 foot |
35 to 45 foot |
35 to 45 foot |
| CAYMAN | GYPSY TYPE | LOFRANS PART NUMBER | ||
| 700 wattage | 1000 wattage – 12v | 1000 wattage – 24v | ||
| With Drum | 6mm, ISO 4565 / DIN 766 | 600043 | ||
| 8mm, ISO 4565 / DIN 766 | 220273 | 220279 | ||
| 10mm, ISO 4565 | 419732 | |||
| 10mm, DIN 766 | 600162 | 600180 | ||
